1. Select an model version and select Prepare for RED from the Workflow pane.
   The Prepare for RED dialog is displayed.
   Image Removed Image Added


   Note
   title Note
   If you DO NOT have any target locations configured, the No target locations found dialog is displayed.   Click Create to open Target location descriptors dialog. When you close the dialog, the Prepare for RED dialog is displayed. Click Continue if you do not want to create target locations and proceed with the wizard.

2. Select a Category or a Model, enter a Name and Version for the model and click Create.


   Tip
   title Tip
   If you select a Model then you only need to enter a Version.

   The Prepare for RED - Settings dialog is displayed.
   Image RemovedImage Added
3. Select your Target RDBMS and click Next.
   The Manual type mapping dialog is displayed.
   Image RemovedImage Added


   Tip
   title Tip
   The Manual type mapping dialog is ONLY displayed if you have modified entity types.

4. Resolve any missing entity types and attribute types coming from your model and click Finish.
   The Prepare for RED complete dialog is displayed.
   Image RemovedImage Added
5. Click Next.
   The Prepare for RED - Manage target locations dialog is displayed. From this dialog you can manage the target locations for all the entities in this model version.
   Image RemovedImage Added
   Complete the following:
   • Entities - Select a filter to first filter on certain entities and then to select the checkboxes to select relevant entities.
   • Target locations - Select a target location from the drop-down list and click Move to move the selected entities to the selected location.
6. Click Update.
   The Prepare for RED - Manage groups dialog is displayed.
   Image RemovedImage Added
7. Click to define a group to correlate with a WhereScape RED project, select all the tables you want to include in the group and click Update.
   The Prepare for RED - Apply data type mappings dialog is displayed.
   Image RemovedImage Added
8. Complete the following...:
   • Select the source database type from the From list (if required).
   • Select the Letter case from the drop-down list to be used for the data type names.
   • Select an entity type from Add data transformations to. The data transformation will be added, if it has been defined in the data type mapping definition and only to entities of the selected entity type. By default, the Load entity type is selected.
9. Click Next.
   The Prepare for RED - Apply data type mappings dialog is displayed.
   Image RemovedImage Added
10. Click Next.
    The Prepare for RED - Apply model conversion dialog is displayed.
    Image RemovedImage Added
11. Complete the following...
    • Click to add a new model conversion entry.
    • Select a new rule from the drop-down list.
    • Click to reset to the default settings.
    • Drag the handle to reorder the model conversions.
12. Click Next.
    The Prepare for RED - Applying model conversion dialog is displayed.
    Image RemovedImage Added
13. Click Finish.
    The diagram is displayed.
    Image RemovedImage Added
