What is Webview2?

WebView2 allows embedding an Edge browser within a Windows application, meaning webpages can be viewed within the application frame.

Visual LANSA V16 introduces a new Primitive for Webview2 called PRIM_WEBV. This allows a modern browser to be embedded into a user's VL Windows application, giving them access to the browser controls to build their own UI around it.

Using WebView2

Component Definition

The Visual LANSA Primitive for WebView2 provides standard web page controls (Navigate, Back, Forward, Stop, and Reload) along with access to navigation events, such as starting and completing, to help manage and customize your UI.

     Define_Com Class(#PRIM_WEBV) Name(#WebView) Parent(#COM_OWNER) Displayposition(1) Tabposition(1) Height(890) Top(116) Left(0) Width(1659) Defaulturl('https://docs.lansa.com/15/en/')

Properties

CanNavigateBack

Returns a Boolean as to whether the browser can navigate back in history.

CanNavigateForward

Returns a Boolean as to whether the browser can navigate forward in history.

DocumentTitle

Returns a string that is the title of the current HTML document.

DefaultURL

Sets the URL which will load once the WebView is initialized.

Source

Returns the current URL in the WebView component.

Here is an example of using these properties to control your UI:

     Mthroutine Name(ToggleControls)

        #BTN_Back.Enabled := #WebView.CanNavigateBack
        #BTN_Forward.Enabled := #WebView.CanNavigateForward
        #URL := #WebView.Source
        #COM_OWNER.Caption := #WebView.DocumentTitle

     Endroutine

Methods

NavigateBack

Navigates back in history.

     Evtroutine Handling(#BTN_Back.Click)
        #WebView.NavigateBack
     Endroutine

NavigateForward

Navigates forward in history.

     Evtroutine Handling(#BTN_Forward.Click)
        #WebView.NavigateForward
     Endroutine

NavigateTo

Navigates to the URL input as the URL parameter.

     Evtroutine Handling(#BTN_Go.Click)
        #WebView.NavigateTo( #COM_SELF.FormatURL )
     Endroutine

Reload

Reload the current webpage.

     Evtroutine Handling(#BTN_Reload.Click)
        #WebView.Reload
     Endroutine

Stop

Stops the loading of a webpage.

     Evtroutine Handling(#BTN_Stop.Click)
        #WebView.Stop
     Endroutine

Events

NavigationComplete

Fired when the loading of a webpage has finished.

     Evtroutine Handling(#WebView.NavigationCompleted) Options(*NOCLEARMESSAGES *NOCLEARERRORS)
        #Navigating := False
        #COM_SELF.ToggleControls
        #URL := #WebView.Source
     Endroutine

NavigationStarting

Fired when the Loading of a webpage commences.

     Evtroutine Handling(#WebView.NavigationStarting) Options(*NOCLEARMESSAGES *NOCLEARERRORS)
        #Navigating := True
        #COM_SELF.ToggleControls
     Endroutine

Sample

     * **************************************************
     *
     *  COMPONENT:  STD_FORM*
     *
     * **************************************************
     Function Options(*DIRECT)
     Begin_Com Role(*EXTENDS #PRIM_FORM) Clientwidth(1659) Clientheight(1006) Componentversion(2) Left(1065) Top(203) Layoutmanager(#LayoutMain)

     Define_Com Class(#PRIM_VS.Style) Name(#Style1) Cornerbottomleft(0) Cornerbottomright(0) Borderleft(0) Bordertop(0) Borderright(0) Borderbottom(0)


     Define_Com Class(#PRIM_TBLO) Name(#LayoutMain)
     Define_Com Class(#PRIM_TBLO.Column) Name(#LayoutMainColumn1) Displayposition(1) Parent(#LayoutMain)
     Define_Com Class(#PRIM_TBLO.Row) Name(#LayoutMainRow1) Displayposition(3) Parent(#LayoutMain) Height(2)
     Define_Com Class(#PRIM_TBLO.Row) Name(#LayoutMainRow2) Displayposition(1) Parent(#LayoutMain) Height(58) Units(Pixels)
     Define_Com Class(#PRIM_TBLO.Row) Name(#LayoutMainRow3) Displayposition(2) Parent(#LayoutMain) Height(58) Units(Pixels)
     Define_Com Class(#PRIM_TBLO.Item) Name(#LayoutMainItem1) Manage(#WebView) Parent(#LayoutMain) Row(#LayoutMainRow1) Column(#LayoutMainColumn1)
     Define_Com Class(#PRIM_TBLO.Item) Name(#LayoutMainItem2) Alignment(TopLeft) Column(#LayoutMainColumn1) Manage(#Label1) Parent(#LayoutMain) Row(#LayoutMainRow2) Sizing(FitToWidth) Flow(Down) Marginleft(8) Marginright(8)
     Define_Com Class(#PRIM_TBLO.Item) Name(#LayoutMainItem3) Alignment(TopLeft) Column(#LayoutMainColumn1) Manage(#URL) Parent(#LayoutMain) Row(#LayoutMainRow2) Sizing(FitToWidth) Flow(Down) Marginleft(24) Marginright(24)
     Define_Com Class(#PRIM_TBLO.Item) Name(#LayoutMainItem4) Alignment(TopLeft) Column(#LayoutMainColumn1) Manage(#Label2) Parent(#LayoutMain) Row(#LayoutMainRow3) Sizing(FitToWidth) Flow(Down) Marginleft(8) Marginright(8)
     Define_Com Class(#PRIM_TBLO.Item) Name(#LayoutMainItem5) Alignment(TopLeft) Column(#LayoutMainColumn1) Manage(#Panel1) Parent(#LayoutMain) Row(#LayoutMainRow3) Sizing(FitToWidth) Flow(Down) Marginleft(16) Marginright(16)
     Define_Com Class(#PRIM_TBLO.Item) Name(#LayoutMainItem6) Alignment(BottomCenter) Column(#LayoutMainColumn1) Manage(#ProgressBar) Parent(#LayoutMain) Row(#LayoutMainRow2) Sizing(FitToWidth) Marginleft(24) Marginright(24)


     Define_Com Class(#PRIM_TBLO) Name(#Layout1)
     Define_Com Class(#PRIM_TBLO.Row) Name(#Layout1Row1) Displayposition(1) Parent(#Layout1)
     Define_Com Class(#PRIM_TBLO.Column) Name(#Layout1Column1) Displayposition(1) Parent(#Layout1)
     Define_Com Class(#PRIM_TBLO.Item) Name(#Layout1Item1) Alignment(CenterLeft) Column(#Layout1Column1) Manage(#BTN_Reload) Parent(#Layout1) Row(#Layout1Row1) Sizing(None) Flow(Right)
     Define_Com Class(#PRIM_TBLO.Item) Name(#Layout1Item2) Alignment(CenterLeft) Column(#Layout1Column1) Manage(#BTN_Forward) Parent(#Layout1) Row(#Layout1Row1) Sizing(None) Flow(Right)
     Define_Com Class(#PRIM_TBLO.Item) Name(#Layout1Item3) Alignment(CenterLeft) Column(#Layout1Column1) Manage(#BTN_Back) Parent(#Layout1) Row(#Layout1Row1) Sizing(None) Flow(Right)
     Define_Com Class(#PRIM_TBLO.Item) Name(#Layout1Item4) Alignment(CenterLeft) Column(#Layout1Column1) Manage(#BTN_Go) Parent(#Layout1) Row(#Layout1Row1) Sizing(None) Flow(Right)
     Define_Com Class(#PRIM_TBLO.Item) Name(#Layout1Item5) Alignment(CenterLeft) Column(#Layout1Column1) Manage(#BTN_Stop) Parent(#Layout1) Row(#Layout1Row1) Sizing(None) Flow(Right)

     Define_Com Class(#PRIM_EDIT) Name(#URL) Parent(#COM_OWNER) Left(24) Top(25) Displayposition(3) Tabposition(2) Width(1611) Height(30)

     Define_Com Class(#prim_WebV) Name(#WebView) Parent(#COM_OWNER) Displayposition(1) Tabposition(1) Height(890) Top(116) Left(0) Width(1659) Defaulturl('https://docs.lansa.com/15/en/')

     Define_Com Class(#PRIM_LABL) Name(#Label1) Caption('URL') Displayposition(2) Ellipses(Word) Height(25) Left(8) Parent(#COM_OWNER) Tabposition(3) Tabstop(False) Top(0) Verticalalignment(Center) Width(1643)
     Define_Com Class(#PRIM_PANL) Name(#Panel1) Displayposition(5) Left(16) Parent(#COM_OWNER) Tabposition(4) Tabstop(False) Top(83) Width(1627) Layoutmanager(#Layout1) Height(30)
     Define_Com Class(#PRIM_PHBN) Name(#BTN_Go) Caption('Go') Displayposition(1) Left(0) Parent(#Panel1) Tabposition(1) Top(3)
     Define_Com Class(#PRIM_PHBN) Name(#BTN_Back) Caption('Back') Displayposition(2) Left(80) Parent(#Panel1) Tabposition(2) Top(3)
     Define_Com Class(#PRIM_PHBN) Name(#BTN_Forward) Caption('Forward') Displayposition(3) Left(160) Parent(#Panel1) Tabposition(3) Top(3)
     Define_Com Class(#PRIM_PHBN) Name(#BTN_Reload) Caption('Reload') Displayposition(4) Left(240) Parent(#Panel1) Tabposition(4) Top(3)
     Define_Com Class(#PRIM_PHBN) Name(#BTN_Stop) Caption('Stop') Displayposition(5) Left(320) Parent(#Panel1) Tabposition(5) Top(3)
     Define_Com Class(#PRIM_LABL) Name(#Label2) Caption('Controls') Displayposition(4) Ellipses(Word) Height(25) Left(8) Parent(#COM_OWNER) Tabposition(5) Tabstop(False) Top(58) Verticalalignment(Center) Width(1643)
     Define_Com Class(#PRIM_PGBR) Name(#ProgressBar) Displayposition(6) Left(24) Parent(#COM_OWNER) Tabposition(6) Top(38) Width(1611) Height(20) Style(#Style1) Visible(False)
     Define_Com Class(#PRIM_TIMR) Name(#ProgressTimer) Interval(25) Startup(Manual)
     Define_Com Class(#prim_nmbr) Name(#ProgressNum)
     Define_Com Class(#PRIM_BOLN) Name(#Navigating)


     Evtroutine Handling(#COM_OWNER.Initialize)
     #URL := #WebView.DefaultUrl
     Endroutine

     Evtroutine Handling(#WebView.NavigationCompleted) Options(*NOCLEARMESSAGES *NOCLEARERRORS)
     #Navigating := False
     #COM_SELF.ToggleControls
     #URL := #WebView.Source
     Endroutine

     Evtroutine Handling(#WebView.NavigationStarting) Options(*NOCLEARMESSAGES *NOCLEARERRORS)
     #Navigating := True
     #COM_SELF.ToggleControls
     Endroutine

     Evtroutine Handling(#BTN_Go.Click)
     #WebView.NavigateTo( #COM_SELF.FormatURL )
     Endroutine
     Evtroutine Handling(#URL.Enter)
     #WebView.NavigateTo( #COM_SELF.FormatURL )
     Endroutine
     Evtroutine Handling(#BTN_Back.Click)
     #WebView.NavigateBack
     Endroutine
     Evtroutine Handling(#BTN_Forward.Click)
     #WebView.NavigateForward
     Endroutine
     Evtroutine Handling(#BTN_Reload.Click)
     #WebView.Reload
     Endroutine
     Evtroutine Handling(#BTN_Stop.Click)
     #WebView.Stop #COM_SELF.ToggleControls
     Endroutine


     Mthroutine Name(FormatURL)
     Define_Map For(*RESULT) Class(#prim_dc.UnicodeString) Name(#Result)

     Define Field(#Protocol) Type(*NVARCHAR) Length(8)

     #Protocol := #URL.Value.Substring( 1 8 ).UpperCase

     If (#Protocol.UpperCase <> 'HTTPS://')

     #Protocol := #URL.Value.Substring( 1 7 ).UpperCase

     If (#Protocol.UpperCase <> 'HTTP://')

     #URL := 'https://' + #URL

     Endif

     Endif

     #Result := #URL

     Endroutine

     Mthroutine Name(ToggleControls)

     #BTN_Back.Enabled := #WebView.CanNavigateBack
     #BTN_Forward.Enabled := #WebView.CanNavigateForward
     #BTN_Stop.Enabled := #Navigating
     #BTN_Reload.Enabled := #Navigating.IsFalse
     #BTN_Go.Enabled #URL.Enabled := #Navigating.IsFalse

     #COM_OWNER.Caption := #WebView.DocumentTitle
     If (#Navigating)
     #ProgressBar.FadeIn Duration(250)
     #ProgressTimer.Start
     Else
     #ProgressTimer.Stop
     #ProgressBar.Value := 0
     #ProgressBar.FadeOut Duration(250) Visible(True)
     Endif

     Endroutine

     Evtroutine Handling(#ProgressTimer.Tick) Options(*NOCLEARMESSAGES *NOCLEARERRORS)

     #ProgressBar.Value += 1

     If (#ProgressBar.Value >= 100)
     #ProgressNum := 0
     Endif

     #Com_owner.UpdateDisplay


     Endroutine
     End_Com
